Product Description
The DRW200P is a compact and cost-effective portable water well drilling rig designed for small to medium-scale drilling projects. Powered by a reliable diesel engine, it combines percussion and rotary drilling methods to deliver stable performance, high efficiency, and easy operation in various ground conditions.
With its lightweight structure and simple transport design, the DRW200P is an ideal solution for rural water supply, agricultural irrigation, garden wells, and small construction projects.
Key Advantages
The DRW200P is engineered for flexibility, efficiency, and affordability, making it an excellent entry-level drilling machine for global markets:
Compact & Portable Design – Lightweight structure (1000–1500 kg) for easy transportation and relocation
Efficient Drilling Performance – Combines percussion and rotary drilling for faster penetration
Large Bore Capacity – Drilling diameter up to Ø450 mm to meet various water pump requirements
Automatic Rod Changing System – Full threaded connection for faster and safer operation
Cost-Effective Solution – 25HP diesel engine with low fuel consumption and easy maintenance
Technical Specifications
| Model | DRW200P |
| Overall Dimension | 1800 × 1000 × 2000 mm |
| Weight | 1000 – 1500 kg |
| Drill Rod Diameter | Ø50 mm |
| Drill Rod Length | 1500 mm |
| Rod Connection | Full automatic threaded connection |
| Max Drilling Depth | 150 m |
| Hole Diameter | Up to Ø450 mm |
| Stroke Distance | 2000 mm |
| Power System | 25 HP Diesel Engine |
| Drilling Method | Percussion & Rotary Type |
| Lifting Capacity | 1200 kg |
Why Choose DRW200P?
The DRW200P is designed for users who need a simple, reliable, and affordable water well drilling solution. It delivers strong performance while maintaining low operating costs, making it highly suitable for contractors, farmers, and small drilling businesses.
Its compact structure allows easy transportation to remote areas, ensuring fast deployment and efficient drilling operations even in challenging environments.
After-sales Service
We provide professional technical support, operator training, spare parts supply and remote troubleshooting assistance. Each DRW200P drilling rig undergoes strict quality inspection and performance testing before shipment to ensure reliable operation in the field. Our experienced service team is committed to helping customers maximize equipment performance and project productivity.
